Monday, January 16, 2012

Dinkelbach’s Algorithm

The paper:

Dinkelbach’s Algorithm as an Efficient Method for Solving a Class of
MINLP Models for Large-Scale Cyclic Scheduling Problems  [link]

by Prof. Grossmann e.a. investigates some mixed-integer linear fractional programming problems. It compares some standard MINLP codes against an implementation of Dinkelbach’s algorithm and concludes that this algorithm performs very good. The algorithm consists of a solving a series of MIP problems with each time a different weighted objective function. This method is so simple it can be coded in GAMS in just a few lines.

If the problem is something like:


then we need to solve a series of MIP problems:


for different values of λ.

I wanted to see if I could use this on a (very) large mixed-integer linear fractional programming problem. Of course first try it on some very small examples. The first test is a continuous problem:

Example 1: Linear fractional programming problem



$ontext


References:


Fengqi You, Pedro M. Castro, Ignacio E. Grossmann1

Dinkelbach’s Algorithm as an Efficient Method for Solving a Class of

MINLP Models for Large-Scale Cyclic Scheduling Problems


Said Tantawy

AN ITERATIVE METHOD FOR SOLVING LINEAR FRACTION

PROGRAMMING (LFP) PROBLEM WITH SENSITIVITY ANALYSIS

$offtext

set
   i
'products' /a1,a2/
;

parameters
   uprofit(i)
'unit profit' /

a1 4

a2 2

/
   ucost(i)
'unit cost' /

a1 1

a2 2

/
   fixedcost
/5/
   fixedprofit
/10/
   matuse(i)
'raw material usage' /

a1 1

a2 3

/
   rawavail
'raw material available' /30/
;

variables
   x(i)
'production'
   profit
   cost
   z
'objective variable'
;
positive variables x,profit,cost;

equations

   eprofit
'calculate profit'
   ecost
'calculate cost'
   eraw
'raw material usage'
   eprodcon
'production constraint'
   eratio
'minlp objective'
;

eprofit.. profit =e= fixedprofit +
sum(i, uprofit(i)*x(i));

ecost..   cost =e= fixedcost +
sum
(i, ucost(i)*x(i));

eraw..
sum
(i, matuse(i)*x(i)) =l= rawavail;

eprodcon..  x(
'a1') + 5 =g= 2*x('a2'
);

eratio..   z =e= profit/cost;
cost.lo = 1;



*-------------------------------------------------------------

* solve as nlp
*-------------------------------------------------------------

model m1 /all/;
m1.solprint = 2;

solve
m1 maximizing z using nlp;

display "------------------------------------"
,

"NLP Solver"
,

"------------------------------------"
,
        z.l,x.l;


*-------------------------------------------------------------

* Dinkelbach's algorithm
*-------------------------------------------------------------

scalars
  q
'optimal objective at end of algorithm' /0/
  continue
/1/
  tol
/0.1/
  iterations
;


equation linobj;
linobj .. z =e= profit - q*cost;


model m2 /eprofit,ecost,eraw,eprodcon,linobj/
;
m2.solprint = 2;


set iter /iter1*iter5/
;

loop
(iter$continue,

solve
m2 maximizing z using lp;

if
(z.l < tol,
      continue = 0;
      iterations =
ord
(iter);

display "------------------------------------"
,

"Dinkelbach algorithm"
,

"------------------------------------"
,
              q,iterations,x.l;

else

      q = profit.l/cost.l;
   );

);


This continuous problem is very easy:

----     73 ------------------------------------
            NLP Solver
            ------------------------------------
            VARIABLE z.L                   =        3.714  objective variable

----     73 VARIABLE x.L  production

a1 30.000

----    102 ------------------------------------
            Dinkelbach algorithm
            ------------------------------------
            PARAMETER q                    =        3.714  optimal objective at end of algorithm
            PARAMETER iterations           =            2

----    102 VARIABLE x.L  production

a1 30.000

The next small example is an integer problem:

Example 2: an integer fractional programming problem



$ontext


References:


Fengqi You, Pedro M. Castro, Ignacio E. Grossmann1

Dinkelbach’s Algorithm as an Efficient Method for Solving a Class of

MINLP Models for Large-Scale Cyclic Scheduling Problems


Ildiko Zsigmond

Mixed Integer linear Fractional Programming By A Branch-and-Bound

Technique 1985


$offtext


variables
   x1,x2
   num
'numerator'
   denom
'denominator'
   z
'objective variable'
;
integer variables x1,x2;
x1.up = 5;
x2.up = 4;


equations

   enum
'numerator'
   edenom
'denominator'
   e1,e2,e3
   eratio
;

enum.. num =e= 2*x1+x2-2;

edenom..  denom =e= x1-x2+1;

e1.. -5*x1 + 4*x2 =l= 0;
e2.. -x1+x2 =l= 0.5;
e3.. 2*x1+x2 =l= 11;

eratio..   z =e= num/denom;
denom.lo = .1;


option optcr=0;

model m1 /enum,edenom,e1,e2,e3,eratio/
;
m1.solprint = 2;

solve
m1 maximizing z using minlp;

display "------------------------------------"
,

"MINLP Solver"
,

"------------------------------------"
,
        z.l,x1.l,x2.l;




*-------------------------------------------------------------

* Dinkelbach's algorithm
*-------------------------------------------------------------

scalars
  q
'optimal objective at end of algorithm' /0/
  continue
/1/
  tol
/0.1/
  iterations
;


equation linobj;
linobj .. z =e= num - q*denom;


model m2 /enum,edenom,e1,e2,e3,linobj/
;
m2.solprint = 2;


set iter /iter1*iter5/
;

display "------------------------------------"
;
loop
(iter$continue,

solve
m2 maximizing z using mip;
   if (z.l < tol,
      continue = 0;
      iterations =
ord
(iter);

display "------------------------------------"
,

"Dinkelbach algorithm"
,

"------------------------------------"
,
              q,iterations,x1.l,x2.l;

else

      q = num.l/denom.l;
   );

);

The listing file shows:

----     51 ------------------------------------
            MINLP Solver
            ------------------------------------
            VARIABLE z.L                   =        7.000  objective variable
            VARIABLE x1.L                  =        3.000
            VARIABLE x2.L                  =        3.000
----     82 ------------------------------------
            Dinkelbach algorithm
            ------------------------------------
            PARAMETER q                    =        7.000  optimal objective at end of algorithm
            PARAMETER iterations           =        4.000
            VARIABLE x1.L                  =        3.000
            VARIABLE x2.L                  =        3.000

For our very large problem (approx. 1 million rows) this method was even more successful. All NLP solvers I have access to had troubles with the sheer size of the problem, even though the NLP relaxations are linearly constrained. But the MIP problems generated inside Dinkelbach’s algorithm turned out to be large but easy to solve. In addition the algorithm converged in about 5 major iterations.
