Network formulation

I was looking at a model containing underlying traffic network. Such a network can be quite elegantly formulated in GAMS, but apparently many users still have problems with this. The mathematical formulation is:


The GAMS formulation can look like:

$ontext

max flow network example


Data from example in

Mitsuo Gen, Runwei Cheng, Lin Lin

Network Models and Optimization: Multiobjective Genetic Algorithm Approach

Springer, 2008


Erwin Kalvelagen,

Amsterdam Optimization,

May 2008

$offtext

sets
  i
'nodes' /node1*node11/
  source(i)
/node1/
  sink(i)
/node11/
;
alias(i,j);

abort$(card(source)<>1) "We want one source node"
;
abort$(card(sink)<>1) "We want one sink node"
;

parameter capacity(i,j) /


node1.node2 60,   node1.node3 60,   node1.node4 60,   node2.node3 30

node2.node5 40,   node2.node6 30,   node3.node4 30,   node3.node6 50

node3.node7 30,   node4.node7 40,   node5.node8 60,   node6.node5 20

node6.node8 30,   node6.node9 40,   node6.node10 30,  node7.node6 20

node7.node10 40,  node8.node9 30,   node8.node11 60,  node9.node10 30

node9.node11 50,  node10.node11 50 /;

set
arcs(i,j);
arcs(i,j)$capacity(i,j) =
yes
;
display
arcs;

parameter
rhs(i);
rhs(source) = -1;
rhs(sink) = 1;


variables

  x(i,j)
'flow along arcs'
  f
'total flow'
;
positive variables x;
x.up(i,j) = capacity(i,j);


equations

   flowbal(i)
'flow balance' ;

flowbal(i)..

sum(arcs(j,i), x(j,i)) - sum
(arcs(i,j), x(i,j)) =e= f*rhs(i);

model m/flowbal/
;
solve m maximizing f using lp;

1 comment:

  1. or you could just write

    flowbal(i).. sum(arcs(j,i), x(j,i)) - sum(arcs(i,j), x(i,j)) =E= 0 + f*(-1$(source(i) +1$(sink(i))) ;

    :)
