Studentized residuals (the linear case)

I have developed a linear and nonlinear regression solver for GAMS (see and A user asked how to get studentized residuals from these. I probably should add these to the solver so they are written to the GDX file with statistics. But first lets investigate if we can do this at the GAMS level with the current information available.

The residualsresidare returned in the ls.gdx file for the linear regression solver. However to calculate the standard errors of the residuals we need the (diagonals of the) hat matrix:

hat The evaluation of this matrix needs a little bit of attention. It is known from calculating the estimates

regrthat the evaluation of X’X is causing lots of numerical problems. Here is an example of this for the famous Longley data set: However we also export the variance-covariance matrix. This matrix is defined by:

varSo a simple way to evaluate the Hat matrix could be:


Below is a complete GAMS example to calculate the (internally and externally) studentized residuals:


Regression example

Cross-section data: weekly household expenditure on food and
weekly household income from Griffiths, Hill and Judge,
1993, Table 5.2, p. 182.

Erwin Kalvelagen, october 2000


option decimals=8;

* make sure elements are registered in this order:
set dummy /constant,income/;

set i /i1*i40/;

table data(i, *)
expenditure income
i1        9.46       25.83
i2       10.56       34.31
i3       14.81       42.50
i4       21.71       46.75
i5       22.79       48.29
i6       18.19       48.77
i7       22.00       49.65
i8       18.12       51.94
i9       23.13       54.33
i10      19.00       54.87
i11      19.46       56.46
i12      17.83       58.83
i13      32.81       59.13
i14      22.13       60.73
i15      23.46       61.12
i16      16.81       63.10
i17      21.35       65.96
i18      14.87       66.40
i19      33.00       70.42
i20      25.19       70.48
i21      17.77       71.98
i22      22.44       72.00
i23      22.87       72.23
i24      26.52       72.23
i25      21.00       73.44
i26      37.52       74.25
i27      21.69       74.77
i28      27.40       76.33
i29      30.69       81.02
i30      19.56       81.85
i31      30.58       82.56
i32      41.12       83.33
i33      15.38       83.40
i34      17.87       91.81
i35      25.54       91.81
i36      39.00       92.96
i37      20.44       95.17
i38      30.10      101.40
i39      20.90      114.13
i40      48.71      115.46

'estimate constant term coefficient'
'estimate income coefficient'
'sum of squared errors'

'the linear model'


obj..     sse =n= 0;
fit(i)..  data(i,
'expenditure') =e= constant + income*data(i,'income');

option lp=ls;
model ols1 /obj,fit/;
solve ols1 minimizing sse using lp;

display constant.l, income.l, sse.l;

* load covariance matrix and sigma from ls.gdx
set k /constant,income/;
'variance-covariance matrix'
'residual sum of squares'
'degrees of freedom'
execute_load 'ls.gdx',covar,sigma,resid,rss,df;
display covar,resid,sigma,rss,df;

* calculate W= inv(X'X) = COVAR/sigma^2
parameter W(k,k) "inv(X'X)";
alias (k,k2);
W(k,k2) = covar(k,k2)/sqr(sigma);
display W;

* form X
parameter X(i,k);
'constant') = 1;
'income') = data(i,'income');
display X;

* form H = X W X' (only diagonal)
parameter H(i);
h(i) =
sum(k2, sum(k, x(i,k)*w(k,k2)) * x(i,k2));
display h;

* (internally) studentized residuals
* this corresponds to stdres in ls.diag in R
parameter stud_res1(i) '(internally) studentized residuals';
stud_res1(i) = resid(i)/[sigma*sqrt(1-h(i))];
display stud_res1;

* (externally) studentized residuals
* this follows the Wikipedia definition
parameter stud_res2(i) '(externally) studentized residuals';
stud_res2(i) = resid(i)/[sqrt[(rss-sqr(resid(i)))/(df-1)]*sqrt(1-h(i))];
display stud_res2;

* (externally) studentized residuals
* this follows the R implementation of
* studres in ls.diag
parameter stud_res3(i) '(externally) studentized residuals R version';
stud_res3(i) = resid(i)/[sqrt[(rss-sqr(resid(i))/(1-h(i)))/(df-1)]*sqrt(1-h(i))];
display stud_res3;

The way I read it the R implementation differs a little bit from the Wikipedia definition. In the code above the calculation of stud_res2 will do what Wikipedia suggests and stud_res3 will mimic what R returns as studres in ls.diag. The difference is a factor 1/(1-h(i)) when taking out the i-th residual. Looking at equation 8.1.17 of Draper and Smith, Applied Regression Analysis, it looks like R is correct and Wikipedia (or rather how I read it) is not. So the version stud_res3 would be the correct one.

For non-linear regression I assume we just need to replace X by J (the Jacobian evaluated at the minimum residual sum of squares).
